Universum CTR 1176, Bestell-Nr. 197.354 4

QUELLE GmbH (Universum); Fürth und Nürnberg

Data
Forum
Pictures
Collections

  • Year
  • 1980 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 256217

 Technical Specifications

  • Number of Transistors
  • 8
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Batteries (any type) / 220 / 7 x 1,5 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Universum CTR 1176, Bestell-Nr. 197.354 4 - QUELLE GmbH Universum; Fürth
  • Dimensions (WHD)
  • 510 x 240 x 125 mm / 20.1 x 9.4 x 4.9 inch
  • Notes

  • 8 Transistoren, 3 IC´s (LA 3361; LA 3220; nicht lesbar).

    4 Lautsprecher, P1245BF 01B, 3,2 Ohm, 6W; 2 Hochtöner ca. 2 cm Durchmesser.

    Platine 090-330801-00, ONWA

  • Net weight (2.2 lb = 1 kg)
  • 3.450 kg / 7 lb 9.6 oz (7.599 lb)
  • Author
  • Model page created by Wolfgang Steeger. See "Data change" for further contributors.
