Universum Gitarren-Verstärker
QUELLE GmbH (Universum); Fürth und Nürnberg
- Country
- Germany
- Manufacturer / Brand
- QUELLE GmbH (Universum); Fürth und Nürnberg
- Year
- 1964 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 350929
- Number of Tubes
- 3
- Number of Transistors
- Semiconductors
- B250C75
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Guitar Amplifier
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Universum Gitarren-Verstärker - QUELLE GmbH Universum; Fürth
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 400 x 295 x 150 mm / 15.7 x 11.6 x 5.9 inch
- Notes
-
Gitarren-Verstärker mit zwei getrennten Anschlüssen für Elektro-Gitarre und Mikrophon oder Plattenspieler. Eingänge mischbar.
Anschluss für Fuss-Fernregler, Klangregler. Mischverstärker mit Phasenumkehr- und Gegentaktendstufe, Frequenzgang 40 - 20.000 Hz.
Fertigung wahrscheinlich in Westdeutschland für die Quelle GmbH Fürth.
- Net weight (2.2 lb = 1 kg)
- 5.5 kg / 12 lb 1.8 oz (12.115 lb)
- Mentioned in
- -- Original prospect or advert (Quelle Katalog 1965/66 (Nachfolgemodell geänderte Form))
- Author
- Model page created by Michael Lienhop. See "Data change" for further contributors.
