Universum - Gitarren Verstärker GV 8/2
QUELLE GmbH (Universum); Fürth und Nürnberg
- Country
- Germany
- Manufacturer / Brand
- QUELLE GmbH (Universum); Fürth und Nürnberg
- Year
- 1965 ??
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 264294
- Number of Transistors
- 8
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Guitar Amplifier
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 6 W (undistorted)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Universum - Gitarren Verstärker GV 8/2 - QUELLE GmbH Universum; Fürth
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 390 x 260 x 140 mm / 15.4 x 10.2 x 5.5 inch
- Notes
-
50 - 20.000 Hz.
Gitarren & Mikrofon Eingang.
DIN Anschluß f. ext. Lautsprecher.
5-25 W Leistungsaufnahme.
- Net weight (2.2 lb = 1 kg)
- 4.2 kg / 9 lb 4 oz (9.251 lb)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
