• Country
• Germany

• Manufacturer / Brand
• QUELLE GmbH (Universum); Fürth und Nürnberg

• Year
• 1989 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 151290

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Record Player + Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 4 Loudspeakers / Ø 10 cm = 3.9 inch

• Power out
• 40 W (unknown quality)

• Material
• Various materials

• from Radiomuseum.org
• Model: Universum HIFI Music Center VTCF 3096A - QUELLE GmbH Universum; Fürth

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 350 x 390 x 350 mm / 13.8 x 15.4 x 13.8 inch

• Notes
• Bestehend aus Plattenspieler(33,3+45U/min) Tuner mit 12 Speicherplätzen (6xAM,6xFM),Doppel-Cassettendeck,Compact-Disc-Spieler, Verstärker mit 5Band Graphic-Equalizer, Kopfhörerbuchse 6,3mm und zwei LSp-Boxen (2x 20W TT+HT).

• Net weight (2.2 lb = 1 kg)
• 7 kg / 15 lb 6.7 oz (15.419 lb)

• Literature/Schematics (1)
• - - Data from my own collection

• Author
• Model page created by Helmut Frings. See "Data change" for further contributors.
