• Country
• Germany

• Manufacturer / Brand
• QUELLE GmbH (Universum); Fürth und Nürnberg

• Year
• 1980 ??

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 309739

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 15

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 8 W (10 W max.)

• Material
• Metal case

• from Radiomuseum.org
• Model: Universum UKW Cassetten Stereo ACR 2765 Bestell-Nummer 015.268 6 - QUELLE GmbH Universum; Fürth

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 180 x 135 x 51 mm / 7.1 x 5.3 x 2 inch

• Notes

• Gerät ist nicht identisch mit ACR 2765, Bestellnummer 929.972 8

• Author
• Model page created by Ralph Oppelt † 3.4.24. See "Data change" for further contributors.
