Universum Volltransistor TR1725 Best.Nr. 02327 / 02328

QUELLE GmbH (Universum); Fürth und Nürnberg

Data
Forum
Pictures
Collections

  • Year
  • 1972 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 268033

 Technical Specifications

  • Number of Transistors
  • 5
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Tuned circuits
  • 4 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / 6LR61: 1 x 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.9 cm = 2.3 inch
  • Power out
  • 0.15 W (undistorted)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Universum Volltransistor TR1725 Best.Nr. 02327 / 02328 - QUELLE GmbH Universum; Fürth
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 110 x 60 x 32 mm / 4.3 x 2.4 x 1.3 inch
  • Notes

  • kleines MW Taschenradio mit 5 Transistoren und 1 Diode,
    Abstimmung und Lautstärkeregler seitlich rechts, Rundskala auf Front, 2,5mm Ohrhöreranschluß links.

    Empfangsbereich:
    520 - 1605kHz

    FTZ-Nr. X153

    Best. Nr. 02327 schwarzes Gehäuse, 02328 rotes Gehäuse.

  • Net weight (2.2 lb = 1 kg)
  • 0.163 kg / 0 lb 5.7 oz (0.359 lb)
  • Author
  • Model page created by Holger Struthoff. See "Data change" for further contributors.
