HiFi-Stereo-Kombination VTCF634 Bestell Nr. 02029 / 06848

• Country
• Germany

• Manufacturer / Brand
• QUELLE GmbH (Universum); Fürth und Nürnberg

• Year
• 1973 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 191585

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 27

• Semiconductors

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)     12 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Record Player + Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 100 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: HiFi-Stereo-Kombination VTCF634 Bestell Nr. 02029 / 06848 - QUELLE GmbH Universum; Fürth

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 575 x 220 x 360 mm / 22.6 x 8.7 x 14.2 inch

• Notes

• HiFi-Stereo-Kompaktanlage mit Radio,
  BSR-Stereo-Plattenspieler 128R und
  Philips-Cassetten-Recorder N2505.

• Net weight (2.2 lb = 1 kg)
• 16.3 kg / 35 lb 14.4 oz (35.903 lb)
