Vibrator Power Supply Unit MI-8319
Radiart Corp.; Cleveland, OH
- Country
- United States of America (USA)
- Manufacturer / Brand
- Radiart Corp.; Cleveland, OH
- Year
- 1941 ??
- Category
- Power supply/conditioner or battery or charger
- Radiomuseum.org ID
- 128530
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- 0Z4
- Wave bands
- - without
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6-8 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Vibrator Power Supply Unit MI-8319 - Radiart Corp.; Cleveland, OH
- Dimensions (WHD)
- 5 x 6.5 x 5.5 inch / 127 x 165 x 140 mm
- Notes
- The MI-8319 is designed for the purpose of adapting the General Purpose Communications Receiver RCA Model AR-88 to 6-volt battery operation.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Geert Schulte. See "Data change" for further contributors.
- Other Models
-
Here you find 17 models, 12 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Radiart Corp.; Cleveland, OH
