• Country
• United States of America (USA)

• Manufacturer / Brand
• Radio Chassis Inc. (RCI); New York (NY)

• Year
• 1932 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 244808

• • Brand: Powerack

• Number of Tubes
• 6

• Valves / Tubes
• 58 57 58 56 47 80

• Main principle
• Superheterodyne (common); ZF/IF 175 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet. / Ø 17 cm = 6.7 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Mercury Superheterodyne 36 - Radio Chassis Inc. RCI; New

• Shape
• Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).

• Dimensions (WHD)
• 350 x 440 x 210 mm / 13.8 x 17.3 x 8.3 inch

• Mentioned in
• Cathedral & Tombstone Radios (page 225.)

• Author
• Model page created by Noemi Erb. See "Data change" for further contributors.

• Other Models

• Here you find 33 models, 4 with images and 17 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
