Radiogram RC-1 + RC-2
Radio Craftsmen Inc., The; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Radio Craftsmen Inc., The; Chicago (IL)
- Year
- 1947–1951
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 225421
- Number of Tubes
- 15
- Main principle
- Superhet with RF-stage; ZF/IF 455/10700 kHz
- Tuned circuits
- 6 AM circuit(s) 11 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 105 - 125 Volt
- Loudspeaker
- -Loudspeaker incorporated, but system not known.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Radiogram RC-1 + RC-2 - Radio Craftsmen Inc., The;
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
The Radio Craftsmen model RC-1 is an AC operated AM-FM superheterodyne tuner with power supply. The 6BA6 functions as RF Amplifier for AM and FM. This was often sold together with the 5-tube RC-2 amplifier, which is a pair. The RC-2 can be found in 1951 Newark catalog Nº 51. This model is perhaps a custom built by using RC-2 and most probably RC-1.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 39, folder 19 = Spring 1948)
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
