Hi-Fi Amplifier RC-2
Radio Craftsmen Inc., The; Chicago (IL)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Radio Craftsmen Inc., The; Chicago (IL)
- Year
- 1947–1951
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 96497
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 10 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Hi-Fi Amplifier RC-2 - Radio Craftsmen Inc., The;
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 10 x 7 x 6 inch / 254 x 178 x 152 mm
- Notes
-
The RC-2 is the first Audio Amplifier made by "The Radio Craftsmen", together with a tuner RC-1, made for the RC-2. The Tuner RC-1 and this RC-2 were used to build into different cabinets - like this radiogram.
- Price in first year of sale
- 43.00 $
- External source of data
- 1951 Newark catalog Nº 51
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 39, Folder 19 = Spring 1948)
- Author
- Model page created by Vitor Oliveira. See "Data change" for further contributors.
