Band Expander DM-36
Radio Mfg. Engineers, Inc. (RME); Peoria, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Radio Mfg. Engineers, Inc. (RME); Peoria, IL
- Year
- 1941 ??
- Category
- Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
- Radiomuseum.org ID
- 52548
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- RF Converter/Adapter (not voltage converter)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Band Expander DM-36 - Radio Mfg. Engineers, Inc. RME
- Shape
- Tablemodel, with any shape - general.
- Notes
- Frequency converter, converts the 28-30 and 56-60 MHz ham bands to 10 MHz.
- Circuit diagram reference
- Rider's Perpetual, Volume 12 = ca. 1941 and before
- Author
- Model page created by Peter Rutishauser. See "Data change" for further contributors.
