6T53 Ch= KCS47AT
Radio Electrola - see RCA Victor Co., Inc.
- Country
- United States of America (USA)
- Manufacturer / Brand
- Radio Electrola - see RCA Victor Co., Inc.
- Year
- 1950 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 342127
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 22
- Valves / Tubes
- 6CB6 6J6 6AU6 6AU6 6AL5 6AV6 6K6GT 6AU6 6CB6 6AU6 6CB6 6AL5 12AU7 12AU7 6SN7GT 6K6GT 6SN7GT 6BG6G 6W4GT 1B3GT 5U4G 16GP4 or 16GP4A or 16GP4B or 16GP4C
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 6T53 Ch= KCS47AT - Radio Electrola - see RCA
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
The RCA 6T53 is a 16" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis KCS47AT, picture tube 16GP4, 16GP4A, 16GP4B or 16GP4C.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 113 folder 7 dated 50)
- Literature/Schematics (2)
- Photofact Folder, Howard W. SAMS (Set 120 folder 1 Production changes bulletin 12 dated 1-51)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
