DAE-1 Radio Direction Finder Equipment CRM-46153 & CRM-69074
Radiomarine Corporation of America, New York
- Country
- United States of America (USA)
- Manufacturer / Brand
- Radiomarine Corporation of America, New York
- Year
- 1943 ?
- Category
- Military Receiver
- Radiomuseum.org ID
- 330128
-
- alternative name: RMCA
Navy DAE-1 Radio Direction Finder receiver
DAE_loop CRM-69074
Navy DAE-1 Radio Direction Finder_ ID tag
- Number of Tubes
- 8
- Main principle
- Superhet with RF-stage; ZF/IF 175 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: DAE-1 Radio Direction Finder Equipment CRM-46153 & CRM-69074 - Radiomarine Corporation of
- Shape
- Tablemodel, with any shape - general.
- Notes
-
The DAE is a direction finder, It is a superhet receiver covering 240 to 2000 kHz. The direction-finder loop is separate from the receiver for installations aboard ship. The input is from a loop and sense antenna. The output to headphones is 600 ohms. A BFO is provided for CW reception but no AVC is available. Model DAE-1 consists of CRM-46153 Radio Receiver and CRM-69074 Loop Assembly.
- Mentioned in
- -- Original-techn. papers. (Catalog of Naval Electronic Equipment, April 1946.)
- Author
- Model page created by Rich Post. See "Data change" for further contributors.
