• Country
• Norway

• Manufacturer / Brand
• Radionette; Oslo

• Year
• 1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 289870

• Number of Tubes
• 6

• Valves / Tubes
• 6J8G EF9 EBC3 6L6GT 6G5 5Y3G

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 150; 230 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 23 cm = 9.1 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Verdensmottager 1940 - Radionette; Oslo

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 600 x 305 x 260 mm / 23.6 x 12 x 10.2 inch

• Net weight (2.2 lb = 1 kg)
• 14.1 kg / 31 lb 0.9 oz (31.057 lb)

• Author
• Model page created by Andreas Reuther. See "Data change" for further contributors.
