• Country
• Argentina

• Manufacturer / Brand
• Radio Serra S.A.; Buenos Aires

• Year
• 1953 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 194021

• Number of Tubes
• 5

• Valves / Tubes
• UCH42 UF41 UBC41 UL41 UY41

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• AC/DC-set / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Serie N - Radio Serra S.A.; Buenos Aires

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 400 x 270 x 170 mm / 15.7 x 10.6 x 6.7 inch

• Notes
• Esta radio tiene entrada para fono, toma exterior de antena y toma de tierra.
  Onda Corta: 5,9...18 MHz,
  Onda Larga: 540...1610 kHz.

• Author
• Model page created by Dario Marujo. See "Data change" for further contributors.
