Realistic PRO-30 Scanning Receiver 20-9131

Radio Shack (Tandy, Realistic, Micronta); USA

Data
Forum
Pictures
Collections

  • Year
  • 1980 ??
  • Category
  • Amateur-Receiver (amateur bands, may include broadcast bands)
  • Radiomuseum.org ID
  • 325050

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superhet, double/triple conversion; ZF/IF 455/10700 kHz
  • Wave bands
  • Wave Bands given in the notes.
  • Details
  • Scanner - multiband or special
  • Power type and voltage
  • Storage and/or dry batteries / 6 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2 inch = 5.1 cm
  • Power out
  • 0.22 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Realistic PRO-30 Scanning Receiver 20-9131 - Radio Shack Tandy, Realistic,
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 74 x 190 x 46 mm / 2.9 x 7.5 x 1.8 inch
  • Notes

  • Frequency coverage:  68 - 88 MHz FM

                                       108 - 136 MHz AM

                                       138 - 174 MHz FM

                                       380 - 512 MHz FM

    Made in Japan

  • Net weight (2.2 lb = 1 kg)
  • 0.480 kg / 1 lb 0.9 oz (1.057 lb)
  • Mentioned in
  • -- Original-techn. papers.
  • Author
  • Model page created by Ottmar Rollmann. See "Data change" for further contributors.
