• Country
• Czechoslovakia

• Manufacturer / Brand
• Radiotechna, spol. s r. o., Praha-Prelouc

• Year
• 1937/1938

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 23296

• • alternative name: Kresl & spol, CS
  • Brand: Telefunken Praha

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• ACH1 AF3 AF3 ABC1 AM2 AD1 AZ1

• Main principle
• Superheterodyne (common); ZF/IF 484 kHz

• Tuned circuits
• 9 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 200; 220; 240 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 30 cm = 11.8 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Hymnus - Radiotechna, spol. s r. o.,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 700 x 400 x 280 mm / 27.6 x 15.7 x 11 inch

• Notes
• Spiegelskala; variable Bandbreitenregelung auf 2 ZF-Bandfilter. Dial lamp: 4V/0,6A.

• Price in first year of sale
• 3,190.00 Kc

• External source of data
• Erb

• Source of data
• Ceskoslovenske prijimace 1933-1945, Baudys 1947

• Other Models

• Here you find 69 models, 62 with images and 53 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
