- Country
- Latvia (Latvia, Riga)
- Manufacturer / Brand
- Radiotehnika (RT) - after 1951 RRR Rigas Radio Rupnica; Riga
- Year
- 1963
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 137175
-
- alternative name: A. Ss. Popow, Riga || Kandava Radio Works || Riga Popov Radiotechnika Works
Skala Bruchschäden
- Number of Transistors
- 7
- Semiconductors
- Main principle
- ZF/IF 465 kHz
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 0.14 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Convair S - Radiotehnika RT - after 1951
- Dimensions (WHD)
- 170 x 100 x 40 mm / 6.7 x 3.9 x 1.6 inch
- Notes
- Selga (1963) Export variation.
- Net weight (2.2 lb = 1 kg)
- 0.6 kg / 1 lb 5.1 oz (1.322 lb)
- Source of data
- - - Data from my own collection
- Literature/Schematics (1)
- Rences Tamás: Rádió kapcsolások, Budapest, 1971.
- Author
- Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
