Rigonda Marksman-Audio
Radiotehnika (RT) - after 1951 RRR Rigas Radio Rupnica; Riga
- Country
- Latvia (Latvia, Riga)
- Manufacturer / Brand
- Radiotehnika (RT) - after 1951 RRR Rigas Radio Rupnica; Riga
- Year
- 1968–1971
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 125991
-
- alternative name: A. Ss. Popow, Riga || Kandava Radio Works || Riga Popov Radiotechnika Works
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case
- from Radiomuseum.org
- Model: Rigonda Marksman-Audio - Radiotehnika RT - after 1951
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 470 x 235 x 270 mm / 18.5 x 9.3 x 10.6 inch
- Notes
- UK export version of "RIGA-101" model, FM (Stereo) 88-104 MHz, 3 SW bands, built-in VHF/FM aerial, front controlled turnable ferrit antenna, DIN tape terminal, phono-in, set consists of two suitable speaker boxes type "AC 80-2-1" with 470×235×200 mm.
- Source of data
- -- Collector info (Sammler)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
