• Country
• Germany

• Manufacturer / Brand
• Radiotone Vertriebs-GmbH, Hamburg

• Year
• 1988 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 152364

• • Brand: RTF Elektro GmbH

• Number of Transistors
• 2

• Semiconductors
• unknown_tr TDA1083

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 220/ 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.5 cm = 3 inch

• Power out
• 1 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 2 Band Kofferradio PRR150 - Radiotone Vertriebs-GmbH,

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 220 x 125 x 45 mm / 8.7 x 4.9 x 1.8 inch

• Notes

• starrer Tragegriff

• Net weight (2.2 lb = 1 kg)
• 0.650 kg / 1 lb 6.9 oz (1.432 lb)

• Author
• Model page created by Klemens Rhode. See "Data change" for further contributors.

• Other Models

• Here you find 19 models, 18 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
