Unknown 1
Radiovision; Leicester
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Radiovision; Leicester
- Year
- 1947 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 343938
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); 2 AF stage(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 200-215; 220-230; 240-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 19 cm = 7.5 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Unknown 1 - Radiovision; Leicester
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 530 x 250 x 230 mm / 20.9 x 9.8 x 9.1 inch
- Notes
-
Wave bands:
- MW 200...550 m
- SW1 11...36 m
- SW2 35...100 m
- Author
- Model page created by Antonio Martins-Pais. See "Data change" for further contributors.
