• Country
• Germany

• Manufacturer / Brand
• Rafena Werke Radeberg, VEB; Radeberg (Ostd.)

• Year
• 1958

• Category
• Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

• Radiomuseum.org ID
• 88699

• • Brand: VEB Rafena; Radeberg (Ostd.)

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 15

• Valves / Tubes
• ECC84 ECF82 EF80 EF80 EF80 EF80 EF80 EABC80 EL83 ECL81 ECL82 ECC82 EL81 EY81 EY51

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 11 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110;127;220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Clivia FER858A/D, L - Rafena Werke Radeberg, VEB;

• Shape
• Console with Push Buttons.

• Notes
• Fernesehtruhe zusammen mit einem "Beethoven/R" von Sternradio Rochlitz

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Mario Spitzer. See "Data change" for further contributors.
