Hornparabolantenne (Spiegel) 8040/T
Rafena Werke Radeberg, VEB; Radeberg (Ostd.)
- Country
- Germany
- Manufacturer / Brand
- Rafena Werke Radeberg, VEB; Radeberg (Ostd.)
- Year
- 1970 ?
- Category
- Antenna (Aerial) or Coupler
- Radiomuseum.org ID
- 342601
-
- Brand: VEB Rafena; Radeberg (Ostd.)
- Wave bands
- Wave Bands given in the notes.
- Loudspeaker
- - - No sound reproduction output.
- Material
- Various materials
- from Radiomuseum.org
- Model: Hornparabolantenne 8040/T - Rafena Werke Radeberg, VEB;
- Shape
- Miscellaneous shapes - described under notes.
- Dimensions (WHD)
- 3900 x 6370 x 3000 mm / 153.5 x 250.8 x 118.1 inch
- Notes
-
Die Hornparabolantenne 8040/T wird für den Frequenzbereich von 3,4 ... 3,9 GHz als Sende- und Empfangsantenne in Richtfunkanlagen verwendet.
Gewinn 37 dB, Rückwärtsdämpfung > 60 dB
Ausgelegt für maximale Windgeschwindigkeit von 220 km/h
- Net weight (2.2 lb = 1 kg)
- 999 kg / 2200 lb 7 oz (2200.441 lb)
- Mentioned in
- - - Manufacturers Literature
- Author
- Model page created by Wolfgang Lill. See "Data change" for further contributors.
