1007

Vica (Talleres), Capdevila; Barcelona

Data
Forum
Pictures
Collections

  • Year
  • 1946
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 87585

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast plus 2 Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 1007 - Vica Talleres, Capdevila;
  • Shape
  • Console with Push Buttons.
  • Notes

  • The tube "unknown" is given as tube M1D6. We did not find this tube in books and the uploader did not respond. Who knows more?

    Altavoz electrodinámico, Melodial EZ5-PB

  • Mentioned in
  • Museo de la radio de Ponferrada (León)

 Collections | Museums | Literature

Collections

The model is part of the collections of the following members.

 Forum

Forum contributions about this model: Vica Talleres,: 1007

Threads: 1 | Posts: 1

Al estar en posesion del aparato de radio Vica 1007 puedo aportar que las valvulas que tengo y creo que son originales  ( puedo poner fotos ) son las siguientes 6k7gt - 6K7gt - 6Q7g - 6L6 - EZ80

Asimismo segun las fotos que he aportado este modelo tiene el altavoz de 200m/m de diametro y es electrodinamico .Tambien segun se indica en una foto su placa dice que su tension es 125 V. y con esta tension la hago funcionar , va muy bien , saludos .



Armand Reig Gonzalez, 26.Feb.20
