• Country
• Denmark

• Manufacturer / Brand
• Rank-Arena, Horsens

• Year
• 1971 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 164823

• • Brand: Arena

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 64

• Semiconductors

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 12 AM circuit(s)     14 FM circuit(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 75 W (unknown quality)

• Material
• Various materials

• from Radiomuseum.org
• Model: Arena T9000 - Rank-Arena, Horsens

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 515 x 150 x 300 mm / 20.3 x 5.9 x 11.8 inch

• Notes
• Wellenbereiche: MW1: 515-1030 kHz,UKW: 87,5 -108,5 MHz.Gehäuse: Metall mit Holzverkleidung. Gerätetyp: Receiver (Tuner mit Vollverstärker).

• Net weight (2.2 lb = 1 kg)
• 20 kg / 44 lb 0.8 oz (44.053 lb)

• Source of data
• - - Manufacturers Literature

• Literature/Schematics (1)
• Arena Manual T 9000

• Author
• Model page created by Lothar Bochem. See "Data change" for further contributors.
