Lectron Series 2

Raytheon Mfg. Co.; Cambridge, MA

Data
Forum
Pictures
Collections

  • Year
  • 1968
  • Category
  • Kit (Parts plus instruction) or building instructions only
  • Radiomuseum.org ID
  • 211410

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 2
  • Main principle
  • 2 AF stage(s)
  • Tuned circuits
  • 1 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / 9 Volt
  • Loudspeaker
  • - only for Earphone!
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Lectron Series 2 - Raytheon Mfg. Co.; Cambridge,
  • Notes

  • "See thru" transistorized blocks that connect magnetically to form working experiments that you can see and hear - developed by Egger (-Lectron), Germany.
    Macalaster Scientific Co., a division of Raytheon Education Co., imported this system and developed the special instruction manual.
    Content: 18 building blocks, antenna wire, metal ground plate, instruction manual for 22 experiments.
    This set is the follow-up of Lectron 800, similar to Egger Mini-Lectron / Braun Mini-System).
    The Add-On #4 Box will upgrade this set to Series 3 (follow-up of Lectron 820).
    Price for Raytheon employees: 10 $ plus 0.50 $ postage and sales tax.

  • Price in first year of sale
  • 22.50 USD
