M-2172C Ch= 21T193
Raytheon Mfg. Co.; Cambridge, MA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Raytheon Mfg. Co.; Cambridge, MA
- Year
- 1955 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 333519
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 15
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: M-2172C Ch= 21T193 - Raytheon Mfg. Co.; Cambridge,
- Shape
- Tablemodel, with any shape - general.
- Notes
-
Raytheon model M-2172C is a 21” b/w TV with US standard VHF tuner channels 2 thru 13.
Equipped with chassis 21T193, VHF tuner D-211-24586 and picture tube 21YP4A.
