• Country
• United States of America (USA)

• Manufacturer / Brand
• Raytheon Mfg. Co.; Cambridge, MA

• Year
• 1956

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 83143

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors
• CK760 CK760 CK760 2N133 2N130 2N138 2N138 1N295

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage and/or dry batteries / 6 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: T-2500 Ch= 7RT4 - Raytheon Mfg. Co.; Cambridge,

• Shape
• Tablemodel, with any shape - general.

• Notes

• Two 5.5 inch PM Speakers.

• Circuit diagram reference
• Beitman Radio Diagrams Vol. 17, 1957

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 9-56, Set 329, Folder 11)

• Literature/Schematics (2)
• -- Original prospect or advert (Miami Herald newspaper edition of February 14, 1956)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
