14PD8053U Ch= KCS111D
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1957 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 314525
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Picture from service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 16
- Valves / Tubes
- 3AF4A 4CB6 6CQ8 6CU8 4CB6 6CU8 8AW8A 4AU6 4DT6 6AQ5A 6AQ5A 8CG7 17DQ6A 17AX4GT 1X2B 14ATP4
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Metal case
- from Radiomuseum.org
- Model: 14PD8053U Ch= KCS111D - RCA RCA Victor Co. Inc.; New
- Shape
- Tablemodel, with any shape - general.
- Notes
-
RCA model 14PD8053U is a 14" b/w TV with US standard VHF tuner channels 2 thru 13, and 14 thru 83 UHF. Equipped with chassis KCS111D, VHF-tuner KRK-47-B, UHF-tuner KRK-64-F and picture tube 14ATP4.
