Cathode Ray Oscillograph 151
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1936
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 95851
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Only the AC power cord has been replaced.
Some modern capacitors in power supply.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110-120 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Cathode Ray Oscillograph 151 - RCA RCA Victor Co. Inc.; New
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 13.625 x 8 x 6.25 inch / 346 x 203 x 159 mm
- Notes
-
.
To be used with RCA model 150 Test Oscillator to align high fidelity IF stages.
- Net weight (2.2 lb = 1 kg)
- 14.5 lb (14 lb 8 oz) / 6.583 kg
- Price in first year of sale
- 40.00 $
- Literature/Schematics (1)
- 1938 Radolek Catalog
- Literature/Schematics (2)
- RCA Victor Service Notes "Red Book" Series
- Author
- Model page created by Vitor Oliveira. See "Data change" for further contributors.
