15BP1 Pick-Me-Up Ch= RC-527
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1940
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 53139
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Line / Batteries (any type) / 110-125;1.5/90 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Power out
- 0.15 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 15BP1 Pick-Me-Up Ch= RC-527 - RCA RCA Victor Co. Inc.; New
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 12 x 8 x 6.375 inch / 305 x 203 x 162 mm
- Notes
- brown plastic.
- Net weight (2.2 lb = 1 kg)
- 7.5 lb (7 lb 8 oz) / 3.405 kg
- External source of data
- Ernst Erb
- Source of data
- Collector's Guide to Antique Radios 4. Edition
- Circuit diagram reference
- Rider's Perpetual, Volume 12 = ca. 1941 and before
- Literature/Schematics (1)
- RCA Victor Service Notes "Red Book" Series
