170P048, 107P049, 170P060 Ch= KCS126A

• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1959

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 155721

• • alternative name: RCA Manufacturing || Victor Talking Machine

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• 6EA8 6FV6 6AF4A 6BQ5 6BZ6 6DT6 6BZ6 6AU6 6EW6 6EB8 6DR7 6EA8 6CG7 6AX4GT 1X2B 6DQ6A 5AS4A 17DKP4

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110 - 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• from Radiomuseum.org
• Model: 170P048, 107P049, 170P060 Ch= KCS126A - RCA RCA Victor Co. Inc.; New

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 530 x 420 x 310 mm / 20.9 x 16.5 x 12.2 inch

• Notes
• 17" Television Receiver, Picture tube: 17DKP4, some models are equipped with continuous UHF tuner, tube quantity UHF: 18
  Tuning Range: TV - Channels 2 thru 13, 14 thru 84 UHF.

• Net weight (2.2 lb = 1 kg)
• 19.4 kg / 42 lb 11.7 oz (42.731 lb)

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 9-59, Set 457, Folder 1)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
