1-BT-29 Ch= RC-1187
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1959 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 159291
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Sams Photofact Folders
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 4 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.75 inch = 7 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 1-BT-29 Ch= RC-1187 - RCA RCA Victor Co. Inc.; New
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
- The RCA Victor Model 1-BT-29 is a Battery operated Transitorized Portable AM Receiver.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 6-59, Set 447, Folder 10)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
