1VF224 Ch= RC-1206A + RS-193 (A,B,D)
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1961 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 88313
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Tuned circuits
- 6 AM circuit(s) 8 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- 4 Loudspeakers
- from Radiomuseum.org
- Model: 1VF224 Ch= RC-1206A + RS-193 - RCA RCA Victor Co. Inc.; New
- Notes
- Chassis RC-1206A is an AM/FM-Stereo receiver and used in models: 1-VE-0, 1-VE-1, 1-VE-2, 1-VF-1 and 1-VF-2 Series.
Amplifier Chassis RS-193A,B,D used also in the same Series.
Models of the 1-VF-1 and 1-VF-2 Series have provision for the connection of the multiplex adapter RK-295.
- Circuit diagram reference
- Beitman Radio Diagrams Vol. 22, 1962
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
