21-S-537 "Bromley" Ch= KCS88D

• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1955

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 242893

• • alternative name: RCA Manufacturing || Victor Talking Machine

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 19

• Valves / Tubes
• 6BQ7A 6X8 6CB6 6CB6 6CB6 6X8 12AU7 6AU6 6AL5 6AV6 6AS5 12AU7 6K6GT 6SN7GT 6BQ6GT 6AX4GT 1B3GT or 8016 5U4G 21ZP4B

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 60 cycles, 115 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 8 inch = 20.3 cm

• Power out
• 1.5 W (max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 21-S-537 "Bromley" Ch= KCS88D - RCA RCA Victor Co. Inc.; New

• Shape
• Console with any shape - in general

• Notes

• The RCA 21-S-537 is a 21" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with chassis KCS88D, VHF tuner KRK22D and picture tube 21ZP4B. Uses Qty(2) PM 8" speakers. Has auxiliary audio input jack to permit use of an external record playing attachment. Cabinet color is Mahogany or Blonde Tropical Hardwood.

• Source of data
• - - Manufacturers Literature

• Literature/Schematics (1)
• - - Manufacturers Literature (RCA Datasheet 1954 No. T4 Dated 5-29-54)

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Set 272, Folder 11)

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
