- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1934
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 53288
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Storage and/or dry batteries / 135 & 67.5 & -3 & -7.5 & -4.5 & 2.5 Volt
- Loudspeaker
- Magnetic loudspeaker (reed) generic.
- Power out
- 1.2 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 235-B - RCA RCA Victor Co. Inc.; New
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 24.5 x 41 x 14.25 inch / 622 x 1041 x 362 mm
- Price in first year of sale
- 78.95 USD
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Rider's Perpetual, Volume 5 = ca. 1934 and before
- Literature/Schematics (1)
- RCA Victor Service Notes "Red Book" Series
