6-EY-3B Ch= RS-152E
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1955–1957
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 84582
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Main principle
- Audio-Amplification; 2 AF stage(s)
- Wave bands
- - without
- Details
- Rec.Player+Audio.Amp+LS
- Power type and voltage
- Alternating Current supply (AC) / 60 cycles, 115 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Power out
- 1 W (1.5 W max.)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: 6-EY-3B Ch= RS-152E - RCA RCA Victor Co. Inc.; New
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 13 x 7.125 x 11.875 inch / 330 x 181 x 302 mm
- Notes
-
The RCA 6-EY-3B is an AC operated 2 tube portable 45 r.p.m. record player with automatic record changer. Has Selenium Rectifier. Cabinet is suit-case shaped in two tone green color. Uses record changer RP-190B-5 or RP-190C-4. Record capacity is up to Qty(14) fine groove 7" records.
The RCA Service data covers the following models with chassis variations:
Model Available with Chassis Cabinet Colors 6-EY-3A RS-152A, RS-152B, RS-152D, RS-152E 2 tone brown 6-EY-3B RS-152A, RS-152B, RS-152D, RS-152E 2 tone green 6-EY-3C RS-152A, RS-152B, RS-152D, RS-152E 2 tone blue The RCA Service data covers the following chassis differences:
Chassis Differences RS-152A Basedline chassis RS-152B C2 = 0.0047uF RS-152D V1 changed to 6AV6, R9=820K, C2=0.0047uF RS-152E V1 changed to 6AV6, R2 = 10Meg, R9=390K, Added C7=47pF
- Net weight (2.2 lb = 1 kg)
- 11 lb (11 lb 0 oz) / 4.994 kg
- Literature/Schematics (1)
- - - Manufacturers Literature (RCA Victor Service Data 1955 No. 27 First Edition 8-25-55 and 1955 No. 27 Third Edition 11-10-57)
