6-HF-2 Ch= RC-1154A, RS147

RCA (RCA Victor Co. Inc.); New York (NY)

Data
Forum
Pictures
Collections

  • Year
  • 1956 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 278061
    • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 17
  • Number of Transistors
  • 1
  • Main principle
  • Superhet with RF-stage; ZF/IF 10700/455 kHz
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 110-120 Volt
  • Loudspeaker
  • 3 Loudspeakers
  • Power out
  • 20 W (undistorted)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 6-HF-2 Ch= RC-1154A, RS147 - RCA RCA Victor Co. Inc.; New
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 34.75 x 36 x 18.625 inch / 883 x 914 x 473 mm
  • Notes

  • The RCA VICTOR 6-HF-2 is an AC operated mono combination AM/FM band superheterodyne receiver and record player with automatic record changer.  Equipped with radio chassis RC-1154A, power amplifier chassis RS-147 and 3 speed Automatic Record Changer model RP-197C-5 . The AM band frequency tuning range is 540-1600kHz.  The FM band frequency tuning range is 88-108MHz. Has Qty(2) PM 3.5" speakers and Qty(1) PM 12" speaker. Cabinet was available in either mahogany or blonde oak.

  • Literature/Schematics (2)
  • - - Manufacturers Literature (RCA Victor Service Data 1955 No. 12 dated 5/17/55)
  • Author
  • Model page created by Dirk Taekels. See "Data change" for further contributors.
