• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1955 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 82014

• • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12AX7 12AU7 6E5 12AU7 6X4

• Main principle
• Audio-Amplification

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 115 Volt

• Loudspeaker
• - For headphones or amp.

• from Radiomuseum.org
• Model: 6-HFT-1 Tape Recorder TR-1A - RCA RCA Victor Co. Inc.; New

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Dimensions (WHD)
• 10.5 x 19 x 11 inch / 267 x 483 x 279 mm

• Notes

• The RCA models TR-1 and TR-1A are mechanically and electronically the same except in the volume control connections. In the model TR-1 the volume control is used for the recording level only. In the TR-1A the volume control is used during both recording and playback operation.

  The models TR-1 and TR-1A are also known as the model 6-HFT-1 model.

• Net weight (2.2 lb = 1 kg)
• 26 lb 0 oz (26 lb) / 11.804 kg

• Source of data
• - - Manufacturers Literature

• Circuit diagram reference
• Beitman Radio Diagrams Vol. 16, 1956

• Mentioned in
• - - Manufacturers Literature (RCA Service Data - 1955 No. 15)

• Literature/Schematics (1)
• - - Manufacturers Literature (RCA Service Data - 1955 No. 15)

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Set 377, Folder 15)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
