8TC270 Ch= KCS29,A
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1950 ?
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 244951
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 32
- Valves / Tubes
- 6AG5 6AG5 6J6 6AG5 6AG5 6AG5 6AG5 6AL5 6AU6 6K6GT 6AU6 6AU6 6AL5 6AV6 6K6GT 6V6GT 6SN7GT 6SN7GT 6SN7GT 6K6GT 6SN7GT 6K6GT 6SN7GT 6BG6G 5V4G 1B3GT 1B3GT 5U4G 5U4G 16AP4 6J6 6BA6 6AL5 6AV6
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110-120 Volt
- Loudspeaker
- 3 Loudspeakers / Ø 11.7 inch = 29.7 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 8TC270 Ch= KCS29,A - RCA RCA Victor Co. Inc.; New
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
AM-FM Phono-TV Combination Receiver - some modells TV-only with 16" b/w CRT.
AM 540-1600kc.
FM 88-108Mc.Channels 2 thru 13.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Vol.9/50 Date 2-50 85-13 Set 85 Folder 13)
- Author
- Model page created by Friedrich Weber † 12.09.2014. See "Data change" for further contributors.
