8X546 Ch= RC-1065J
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1949 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 117980
-
- alternative name: RCA Manufacturing || Victor Talking Machine
RECONSTRUCTED LABEL
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 115 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Power out
- 1.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 8X546 Ch= RC-1065J - RCA RCA Victor Co. Inc.; New
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 10.3 x 7 x 5.7 inch / 262 x 178 x 145 mm
- Notes
- color blonde.
- Circuit diagram reference
- Beitman Radio Diagrams Vol. 9, 1949
- Literature/Schematics (1)
- Rider's Perpetual, Volume 18 = covering late 1947 to early 1948 (& vol 20, 21, 22)
- Author
- Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
