- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1929 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 204307
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Data taken from RCA Redbook
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- TRF with regeneration
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Storage and/or dry batteries
- Loudspeaker
- - For headphones or amp.
- Material
- Wooden case
- from Radiomuseum.org
- Model: AR-1145 - RCA RCA Victor Co. Inc.; New
- Shape
- Tablemodel, low profile (big size).
- Notes
- This radio was sold primarily as a short wave receiver and uses 3 different plug-in coils to select the various short wave ranges. Two additional coils allowed reception of the broadcast band.
- Mentioned in
- RCA Victor Service Notes for 1923-1928
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
