• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1939

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 197098

• • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 6SA7 6K7 6H6 6SF5 6F6G 5Y3G

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm

• Power out
• 2.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: K-60 Ch= RC-415B [With Loop Antenna] - RCA RCA Victor Co. Inc.; New

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 25.5 x 38 x 12.5 inch / 648 x 965 x 318 mm

• Notes
• This model is similar to model K-60 (with chassis RC-415) except that this model has a built in loop antenna.

• Net weight (2.2 lb = 1 kg)
• 47 lb (47 lb 0 oz) / 21.338 kg

• Source of data
• RCA Victor Service Notes "Red Book" Series

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
