Auto Radio M32
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1932
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 54332
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 175 kHz
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage and/or dry batteries / 45 x 4 / 6 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet.
- Power out
- 1.25 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Auto Radio M32 - RCA RCA Victor Co. Inc.; New
- Shape
- Chassis only or for «building in»
- Notes
-
Two supply versions: Dry batteries or Storage batt plus dynamotor. Price less batteries or power pack. Some tubes indicate that the model must be from 1932, not 1931!
- Price in first year of sale
- 49.00 $
- External source of data
- Ernst Erb
- Source of data
- Radio Collector`s Guide 1921-1932
- Circuit diagram reference
- Rider's Perpetual, Volume 2 = 1932 (Models 1931/1932)
- Literature/Schematics (1)
- RCA Victor Service Notes "Red Book" Series
