- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1945 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 137442
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Sams photofact.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 105 - 125 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 30 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: MI-13159 - RCA RCA Victor Co. Inc.; New
- Shape
- Tablemodel, low profile (big size).
- Notes
- AC operated 4 channel amplifier.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Folder 4610-26 date12-46)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
