• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1938

• Category
• Power supply/conditioner or battery or charger

• Radiomuseum.org ID
• 53071

• • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• 5T4

• Wave bands
• - without

• Power type and voltage
• Direct Current supply (DC) / 117; 234 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: PSU 10E - RCA RCA Victor Co. Inc.; New

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 12.5 x 8.5 x 5.25 inch / 318 x 216 x 133 mm

• Notes
• DC-mains Power Supply using a Vibrator. Used with Models 10Q1, 12Q4 and 12QK.

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 11 = ca. 1940 and before

• Literature/Schematics (1)
• RCA Victor Service Notes for 1938
