• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1958 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 320479

• • alternative name: RCA Manufacturing || Victor Talking Machine

• Number of Tubes
• 7

• Valves / Tubes
• 6CG7 6CG7 6CG7 6CG7 6BQ5 6BQ5 6BQ5

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz; 110 - 120 Volt

• Loudspeaker
• 3 Loudspeakers / Ø 12 inch = 30.5 cm

• Power out
• 15 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: PVC-245 - RCA RCA Victor Co. Inc.; New

• Shape
• Console, Lowboy (legs < 50 %).

• Dimensions (WHD)
• 32.5 x 30 x 18 inch / 826 x 762 x 457 mm

• Net weight (2.2 lb = 1 kg)
• 25 lb (25 lb 0 oz) / 11.350 kg

• Author
• Model page created by Steve Simon. See "Data change" for further contributors.
