Radio Telegraph Transmitter Model AP-595

RCA (RCA Victor Co. Inc.); New York (NY)

Data
Forum
Pictures
Collections

  • Year
  • 1926 ?
perfect model
  • Category
  • Commercial Transmitter (TX not Transceiver)
  • Radiomuseum.org ID
  • 205532
    • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 2
  • Main principle
  • Transmitter
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Powered by external power supply or a main unit.
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Radio Telegraph Transmitter Model AP-595 - RCA RCA Victor Co. Inc.; New
  • Shape
  • Rack
  • Dimensions (WHD)
  • 16 x 74 x 32 inch / 406 x 1880 x 813 mm
  • Notes

  • RCA Radio Telegraph Transmitter Model AP-595 From the Marine Department at RCA the Model AP-595 transmitter has been developed in order that ships now equipped with spark transmitters may obtain a continuous wave transmitter at minimal cost.

    The Model AP-595 transmitter will cover a wave length band of 1550 to 2600 meters when used with an antenna having a fundamental wave length between 300 and 400 meters and a capacity from .0012 to .oo2 microfarad. T5he power which the Model AP-595 transmitter will deliver to an antenna having an effective resistance at 1800 meters of 3 to 5 ohms, is 200 to 350 watts.

    According to Tyne, page 327/328 the UV204A arrived 1926. Therefore either the first tube line-up was different or the model arrived not before 1926.

  • Net weight (2.2 lb = 1 kg)
  • 600 lb (600 lb 0 oz) / 272.4 kg
  • Source of data
  • - - Manufacturers Literature
  • Author
  • Model page created by Alan Larsen. See "Data change" for further contributors.
