Radiola 25 AR-919

• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1925

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 54643

• • alternative name: RCA Manufacturing || Victor Talking Machine

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• UX199 UX199 UX199 UX199 UX199 UX120 UV877

• Main principle
• Superhet with RF-stage

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case

• from Radiomuseum.org
• Model: Radiola 25 AR-919 - RCA RCA Victor Co. Inc.; New

• Shape
• Tablemodel, slant panel.

• Dimensions (WHD)
• 28 x 10 x 19 inch / 711 x 254 x 483 mm

• Notes
•

• Price in first year of sale
• 165.00 $

• External source of data
• Ernst Erb

• Source of data
• The Radio Collector's Directory and Price Guide 1921 - 1965

• Circuit diagram reference
• Rider's Perpetual, Volume 1 = 1931/1934 (for 1919-1931)

• Mentioned in
• Collector's Guide to Antique Radios 4. Edition ( )

• Literature/Schematics (1)
• Radio Manufacturers of the 1920's, Vol. 3 (Eric P.Wenaas, "Radiola, the Golden Age of RCA")

• Literature/Schematics (2)
• Radio Broadcast, Jan. 1926, p. 305
